1. Wide range of application, equipped with grizzly bar.
2. Reasonable structure design, performance stable and high efficiency.
3. High crushing ratio and low power consumption.
4. Fewer wear parts, easy maintenance.
| Model | Feed Opening (mm) |
Max Feeding size (mm) |
Power (KW) |
Output Size (mm) |
Capacity (TPH) |
Dimension (mm) |
| PCZ1308 | 850X800 | ≤700 | 132 | 0-30 | 100-160 | 2818X2100X2390 |
| PCZ1510 | 1000X850 | ≤800 | 132x2 | 0-30 | 160-210 | 3260X2370X2750 |
| PCZ1512 | 1210X900 | ≤850 | 160x2 | 0-30 | 220-270 | 3260X2580X2750 |
| PCZ1615 | 1500X1200 | ≤1100 | 200x2 | 0-30 | 360-420 | 3456X2915X3185 |
| PCZ2015 | 1500X1400 | ≤1300 | 250x2 | 0-30 | 450-500 | 3880X2990X3560 |
Hammer, rotor, main shaft, liner, impact plate, grate screen, belt pulley, hammer plate, liner bolt, pin, frame, etc.
